Condition：Brand New
Brand：Sinotruk
Driving Type:6x4
Color：Optional
| Driving type | 6 x 4 | Model No | ZZ3257V384JB1R |
| Whole dimension | 8600 x 2500 x 3450 mm | Wheel base | 3825 + 1350 mm |
| Loading weight | 25 - 40 ton | Max speed | 90 km/h |
| Engine | |||
| Engine No | WP 10.380 / WP 12.400 E22 / WP 12.430 | Cylinder No | 6 |
| Fuel type | Diesel | Emission | 9.726 L |
| Emission standard | Euro 2 | Horse power | 380 / 400 / 430 hp |
| Gearbox | |||
| Gearbox no | HW 19710 | Transmission type | Manual |
| Forward | 10 speed | Reverse | 2 speed |
| Dump truck chassis and tire | |||
| Front axle | VGD 9.5 | Front axle loading | 9500 kg |
| Rear axle | MCY16ZG | Rear axle loading | 16000 kg |
| Tires | 12.00 R 20 / 315 / 80 R 22.5 | Tire quantity | 11 , with spare tire |
| Dump box | |||
| Box dimension | ( 5200 - 5800 ) x 2300 x 1500 mm | Hydraulic system | Front/Middle lift |
| Floor thickness | 8 mm | Side thickness | 6 mm |
