Driving type:8x4
Hosre power:371HP/400HP/430HP
Transmission:HW19710
Buckets capacity40-50ton
|
Drive type |
8X4 |
|
|
Wheel base(mm) |
1800+3200+1350 |
|
|
Overall dimension(mm) |
9745×2500×3170 |
|
|
Box dimension(mm) |
6800×2300×1500 |
|
|
Curb weight(Kg) |
12380 |
|
|
Cab |
H77L cabin,flat roof,one and half rows cabin,single sleeper,luxury configuration,A/C |
|
|
Engine |
Model |
WP12.400E201 |
|
Max.output (kw/HP) |
400/430 |
|
|
Max.torque (N•m) |
1500@1100~1600 rpm |
|
|
Displacement (L) |
9.6 |
|
|
Emission standard |
Euro 2 |
|
|
Gear box |
HW19710,manual,10 forward gears & 2 reverse gears |
|
|
Front axle |
VGD95*2 |
|
|
Rear axle |
HC16*2 |
|
|
Steering gear |
Germany brand ZF, LHD/RHD |
|
|
Chassis suspension |
New stabilizing suspension |
|
|
Air intake system |
Double pipe cyclone air duct+Common air filter |
|
|
Inner trimming |
||
|
Standard configuration |
Mechanical suspension seat |
|
|
Lumbar support to the driver |
||
|
Electrical system |
||
|
Standard configuration |
CAN bus intellectual electronic control system |
|
|
New battery box |
||
|
Start/stop device under the vehicle |
||
|
Safety |
||
|
Standard configuration |
Three points safety belt |
|
|
Pneumatic brake |
||
|
Comfortable accessories |
||
|
Cab four points full floating suspension |
Front and rear coil spring |
|
|
Standard configuration |
Cab anti-rolling stabilizing device |
|
|
Hand accelerator |
||
|
Adjustable steering wheel |
||
|
Others |
||
|
Aluminum alloy fuel tank |
300L/Optional |
|
|
Standard configuration |
Big tool box |
|
|
Reinforced rim |
||
|
Three in one lock (ignition switch, door and fuel tank) |
||
|
Tyre specification |
315/80R22.5 12.00R20 |
|
|
Number of tires |
12+1 |
|
|
Thickness of box |
Side 6mm, bottom 8mm |
|
|
Lifting system |
Front hydraulic lifting |
|
