Howo Special Truck

/data/attachment/202004/15/da1a29c20af314a3c1620a6f0df6c449.jpg

  • Product Details
  • Photo Details

Specification
Product Brand
15m3 Disinfectant Sprayer Truck
The first Batch
292
Product Name
dust control sprayer truck
Product Model
CLW5164
Total Weight (Kg)
15800
Volume(m3)
8.5
Rated Weight(Kg)
6325
Overall Dimension(mm)
9350*2500*3850
Curb Weight(Kg)
9280
Cab seats (man)
3
Approach angle/departure angle(°)
20/13
Front overhang/Rear overhang(mm)
1430/2920 1430/2870
Number of axles
2
Wheelbase(mm)
3800,4200,4500,4700,5000
Axle Load(Kg)
5800/10000
Maximum Speed(Km/h)
98
Chassis Specifications
Chassis Model
DFL1160BX1V
Chassis Name
Truck chassis
Brand Name
DONGFENG
Manufacturing enterprise
Dongfeng commercial vehicle co., LTD
Wheel specification
9.00-20,9.00R20,10.00-20,10.00R20
Number of wheels
6
Plate spring count
7/9+6 , 8/10+8
Front gauge(mm)
1880 1900 1920
Fuel Species
Diesel
Track rear(mm)
1800 1860 1820
Engine type
Engine manufacturing enterprise
Displacement(ml)
Power(Kw)
ISD210 50
Dongfeng cumins engine co., LTD
6700
155

Product  Usage

The vehicle is mainly used in anti-aircraft dust (far) process of pesticide spray, coal mine, port, dock dust, industrial and mining
enterprises in specific places. Using on epidemic prevention, sterilization and disinfection in disaster area. Also can used in city’s
haze and dust removal.


Performance&Feature

• The dust suppression vehicles with mobility, the fog system can be electronically controlled operation. It spray out the
atomization uniform, high, far and wide rang. High efficiency and save water.
• The tank is made of high quality manganese plate. Tank interior using advanced butt welding technology, internal use of anti-
corrosion treatment, after tank welding, it’s checked by gas pressure.
• The tank’s shape is square, the internal use of dashboard structure that can prevent the water shaking and impact inside the
tank. Enhance vehicle and tank’s stability. Increase of service life.
• It has sprinkler’s function. The low pressure spray operation and fog gun spray operation can be work together.

• The fog guns have a separate power unit. It can be operated by electronic control.
