Vehicle Model
SHACMAN X3000 6×4 Lorry Truck
Vehicle Type
Cargo Truck / Lorry Truck
Cabin
X3000 High Roof Cabin With Sleeper
Driving Type
Left-hand Drive / Right-hand Drive
Seat Configuration
2 Seats + 1 Sleeper
Cabin Equipment
Air Conditioner, Air Suspension Seat, Electric Window, Central Lock
Engine Brand
WEICHAI / CUMMINS
Engine Model
WP12.430E201
Emission Standard
Euro II / Euro III / Euro V
Transmission Model
12JSD200T
Gearbox
12 Forward & 2 Reverse
Clutch
430 mm Diaphragm Clutch
Rear Axle
16T MAN Double Reduction Axle
Axle Ratio
4.769 / 5.262 Optional
Steering System
ZF Hydraulic Steering
Brake System
Dual Circuit Air Brake
Parking Brake
Spring Energy Brake
Suspension
Heavy-duty Multi-leaf Spring
Tire Specification
12.00R20 / 315/80R22.5
Number Of Tires
10 + 1 Spare Tire
Overall Dimension
9800 × 2550 × 3650 mm
Cargo Body Length
7200 mm
Cargo Body Height
2200 mm
Cargo Body Material
High-strength Steel
Side Wall Type
Fence Type / Stake Type
Payload Capacity
30–40 Tons
Minimum Turning Radius
9.5 m
Application
Logistics / Cargo Transport / Agricultural Transport / Industrial Delivery
Optional Configuration
Customized Configuration Supported
