Vehicle Model
SHACMAN F3000 8×4 Lorry Truck
Vehicle Type
Cargo Truck / Lorry Truck
Cabin
F3000 High Roof Cabin With Sleeper
Driving Type
Left-hand Drive / Right-hand Drive
Seat Configuration
2 Seats + 1 Sleeper
Cabin Equipment
Air Conditioner, Electric Window, Central Lock, Air Suspension Seat
Engine Brand
WEICHAI / CUMMINS
Engine Model
WP12.420E201 / ISM11E5 440
Horsepower
420 HP / 440 HP
Emission Standard
Euro II / Euro III / Euro V
Maximum Torque
1900–2100 N·m
Engine Type
6-cylinder In-line, Turbocharged, Intercooler
Transmission Model
12JSD200T
Gearbox
12 Forward & 2 Reverse
Clutch
Φ430mm Diaphragm Spring Clutch
Rear Axle
16T MAN Double Reduction Axle
Axle Ratio
4.769 / 5.262 / 5.92 Optional
Steering System
ZF Hydraulic Steering
Brake System
Dual Circuit Air Brake
Parking Brake
Spring Energy Brake
Suspension
Heavy-duty Multi-leaf Spring
Tire Specification
12.00R20 / 315/80R22.5
Number Of Tires
12 + 1 Spare Tire
Wheelbase
1800 + 4575 + 1400 mm
Overall Dimension
12000 × 2500 × 3400 mm
Cargo Box Length
9500–9800 mm
Cargo Box Width
2350–2450 mm
Cargo Box Height
600–2500 mm Optional
Cargo Box Type
Flatbed / Stake / Side Wall / Van Cargo
Cargo Floor Thickness
3–5 mm Checkered Plate
Side Wall Thickness
1.5–2.5 mm
Loading Capacity
25–35 Tons
Payload Capacity
25–30 Tons
Electrical System
24V Negative Ground
Paint
Anti-corrosion Primer + Top Coat
Application
General Cargo Transportation / Logistics / Long Distance Transport
Optional Configuration
Customized Configuration Supported
