Vehicle Model
SHACMAN H3000 8×4 Oil Tanker Truck
Vehicle Type
Oil Tanker Truck / Fuel Transport Truck
Cabin Model
H3000 High Roof Cabin
Seat Configuration
2 Seats + 1 Sleeper
Cabin Equipment
Air Conditioner, Air Suspension Seat, Electric Window, Central Lock
Engine Brand
WEICHAI / CUMMINS
Engine Model
WP10 / WP12 / WP13 Series
Horsepower
340 HP / 380 HP / 400 HP / 430 HP
Emission Standard
Euro II / Euro III / Euro V / Euro VI
Displacement
9.726 L / 11.596 L / 12.54 L
Maximum Torque
1600–2300 N·m
Transmission Model
10JSD180 / 12JSD200T
Gearbox
10 Forward & 2 Reverse / 12 Forward & 2 Reverse
Clutch
430 mm Diaphragm Clutch
Front Axle
9.5T MAN Axle ×2
Rear Axle
16T MAN Double Reduction Axle ×2
Axle Ratio
4.769 / 5.262 / 5.92
Steering System
ZF Hydraulic Steering
Brake System
Dual Circuit Air Brake
Parking Brake
Spring Energy Brake
Suspension
Heavy-duty Multi-leaf Spring
Frame
High-strength Reinforced Chassis
Fuel Tank Capacity
300–400 L
Tire Specification
12.00R20 / 315/80R22.5
Number Of Tires
12 + 1 Spare Tire
Wheelbase
1800 + 4575 + 1400 mm
Overall Dimension
11800 × 2550 × 3650 mm
Tank Material
Carbon Steel / Aluminum Alloy
Tank Shape
Elliptical Tank
Tank Capacity
25000–35000 Liters
Compartments
1–6 Compartments Optional
Manhole Cover
European Standard
Bottom Valve
API Pneumatic Bottom Valve
Oil Pump
Self-priming Pump / Gear Pump
Loading System
Top Loading / Bottom Loading
Discharge Method
Pump Discharge / Gravity Discharge
Payload Capacity
25–35 Tons
Application
Diesel, Gasoline, Kerosene, Fuel Oil Transportation
Optional Configuration
Customized Configuration Supported
