Vehicle Model
BEIBEN NG80 6×6 Off-Road Dump Truck
Vehicle Type
Off-Road Dump Truck / Mining Dump Truck
Drive Type
6×6 All-Wheel Drive
Cabin Model
BEIBEN NG80 Reinforced Off-Road Cabin
Driving Position
LHD / RHD Optional
Cab Occupants
2 Persons + Sleeper
Cabin Features
Air Conditioner, Air Suspension Seat, Electric Windows, Central Locking
Engine Model
WP12.430E50 / WP13.480E50 / WP13.550E50
Engine Type
Turbocharged Intercooled Diesel Engine
Horsepower
430HP / 480HP / 550HP
Displacement
11.6L – 12.54L
Maximum Torque
2060–2550 N.m
Emission Standard
Euro II / Euro III / Euro V
Transmission Model
12JSD220TA / 12JSD240TA
Gearbox
12 Forward + 2 Reverse
Transfer Case
Heavy-duty Full-time Transfer Case
Front Axle
9.5T Driven Front Axle
Rear Axle
2×16T Hub Reduction Axles
Differential Lock
Inter-Axle & Cross-Axle Differential Locks
Frame Size
320×90×(10+8) mm
Frame Material
High-strength Alloy Steel
Steering System
ZF Hydraulic Power Steering
Service Brake
Dual Circuit Air Brake
Parking Brake
Spring Energy Brake
Auxiliary Brake
Engine Exhaust Brake
Front Suspension
Heavy-duty Leaf Spring Suspension
Rear Suspension
Mining Bogie Suspension
Fuel Tank Capacity
400L / 500L
Tire Specification
14.00R20 / 14.00R24 Off-road Tire
Number Of Tires
10 + 1 Spare Tire
Minimum Ground Clearance
380 mm
Cargo Body Length
5600–6800 mm
Cargo Body Width
2300–2500 mm
Cargo Body Height
1500–2000 mm
Cargo Body Material
Wear-resistant High-strength Steel
Bottom Plate Thickness
8mm / 10mm / 12mm
Side Plate Thickness
6mm / 8mm
Hydraulic System
HYVA Front Lifting Cylinder
Payload Capacity
25–35 Tons
Application
Forestry Roads, Hydropower Projects, Mountain Engineering, Quarry Operations, Muddy Off-road Transport
Optional Configuration
Customized Body Size, Engine Power, Tire Pattern, Color and Mining Package Available
