Vehicle Model
BEIBEN NG80 8×4 Dump Truck
Vehicle Type
Dump Truck / Tipper Truck
Cabin
NG80 Flat Roof / High Roof Cabin
Driving Type
Left-hand Drive / Right-hand Drive
Seat Configuration
2 Seats + 1 Sleeper
Cabin Equipment
Air Conditioner, Air Suspension Seat, Electric Window, Central Lock
Engine Model
WP12.430E50 / WP13 Series
Horsepower
380 HP / 400 HP / 430 HP / 460 HP
Emission Standard
Euro II / Euro III / Euro V
Transmission Model
12JSD200TA
Gearbox
12 Forward & 2 Reverse
Front Axle
9.5T Heavy-duty Axle ×2
Rear Axle
16T Reduction Axle ×2
Axle Ratio
5.263 / 5.921 Optional
Steering System
ZF Hydraulic Steering
Brake System
Dual Circuit Air Brake
Parking Brake
Spring Energy Brake
Suspension
Heavy-duty Multi-leaf Spring
Tire Specification
12.00R20 / 12R22.5
Number Of Tires
12 + 1 Spare Tire
Wheelbase
1950 + 4050 + 1450 mm
Overall Dimension
10500 × 2550 × 3450 mm
Dump Body Length
7600–8500 mm
Dump Body Height
1500–1800 mm
Cargo Body Material
High-strength Wear-resistant Steel
Lifting System
HYVA Front Hydraulic Lifting
Payload Capacity
30000–40000 kg
Application
Mining / Construction / Quarry / Earthwork Transport
Optional Configuration
Customized Configuration Supported
