Product Specification
Parameter
Specification
Platform
F3000
Drive type
6X4
GVW
10.5 tons
GCW
30 tons
Frame
850×300（8+5+8)mm
Wheelbase
1800+4575+1400 mm
Engine
Weichai/Cummins Euro II
Displacement(L)
10-12L
Horsepower
340-430HP
Transmission
FAST 10 or 12 speed manual
Clutch
φ430
Steering gear
ZF8098
Front axle
MAN 7.5 ton
Rear axle
MAN 16 ton single or double reduction
Gear ratio
4.769 – 5.262
Suspension
Multi leaf spring front and rear setup
Tires
12.00R20
Fuel tank
400 - 700 liter aluminum or steel tank
Cab
Lengthened high/flat roof
Tanker capacity
20CBM
Tonnage
Optional
Configuration
Hydraulic driver seat, four point hydraulic suspension cab, electronically controlled automatic thermostatic air conditioner, electric window lifter, manual turnover, ordinary central air filter, metal bumper, hinged upper pedal, 165ah maintenance free battery, spare tire rack
